Front Frame

BOLT 1/2 UNC X 1-3/4

90-0814
$0.00 excluding shipping

BOLT 1/2-13 X 2-3/4 SHCS

99-16
(USED ON LEFT SIDE)
$2.33 excluding shipping

BOLT 1/2-13 X 2-3/4 NC

90-0822
$0.00 excluding shipping

CABLE CHOKE 31-1/2INKOHLER 42

47-101
(USED ON UNITS WITH KOHLER ENGINES ONLY);NOT ILLUSTRATED
$34.12 excluding shipping

CABLE CHOKE 33.5IN LONG

47-032
(USED ON UNITS WITH KUBOTA ENGINES ONLY);NOT ILLUSTRATED
$24.35 excluding shipping

CAP STEERING WHEEL CENTER

47-104
NOT ILLUSTRATED
$7.36 excluding shipping

DECAL 420 DASH

00-187
Not Illustrated
$0.00 excluding shipping

DECAL CAUTION DO NOT TOW

00-200
(LOCATION: STEERING COLUMN)
$12.11 excluding shipping

DECAL CAUTION SHIFT BOTH TRAN

00-220
(LOCATION: TRANSAXLE SHIFT LEVER)
$6.98 excluding shipping

DECAL FILL WITH TRC FLUID

00-060
(LOCATION: REAR OF FUEL TANK)
$7.95 excluding shipping

DECAL IGNITION SYMBOL

00-089
(LOCATION: KEY SWITCH)
$6.96 excluding shipping

DECAL LIGHT SWITCH SYMBOL

00-075
Not Illustrated
$0.00 excluding shipping

DECAL TRANSAXLE 2-1 SYMBOL

00-103
(LOCATION: FRONT TRANSAXLE SHIFT LEVER)
$7.00 excluding shipping

FRONT FRAME '86 TRACTOR

62-433
$0.00 excluding shipping

GROMMET 1/4 ID X 5/8 OD

05-025
$0.91 excluding shipping

ROD THROTTLE 420 KOHLER

42-487
$0.00 excluding shipping

STEERING WHEEL KELCH

47-103
$89.23 excluding shipping

USE 00-211

00-026
$0.00 excluding shipping

KNOB LARGE

47-003
$8.43 excluding shipping

TUBE NEUTRAL LOCK

40-153
$93.09 excluding shipping
